Desciption

Features:

  • Extra-low dispersion(ED) lenses help to reduce chromatic aberration
  • Push-pull,exposed locking elevation turret with Zero Stop
  • Parallax adjustment and illumination integrated design
  • Compact design is 273mm long and weighs just 640g
  • 30mm main tubes
  • High strength one-piece 6061-T6 aluminum body
  • 10x zoom technology
  • Fast-Focus eyepiece
  • Water proof, shock resistant, and fog resistant
  • Special OEM design body outlook, reticle and special feature per customer request


Technical Specifications:

Model Number
1.5-15X40SFP
Magnification 1.5X-15X
Objective Lens 40mm
Body Tube Diameter 30mm
Focal Plane Second
Length(mm) 273
Weight (g) 640
Field of View (ft@100 yds) 79~7.85ft
Field of View (Degree) 15°~1.5°
Exit Pupil (min.mag - max.mag) (mm) 11~2.67
Eye relief (min.mag - max.mag) (mm) 110~100
Eyepiece Focus Range (dpt) -2/+2
Eyepiece Focusing System Fast Focus
Focus Type Side Focus
Parallax Adjustment 15yds - Infinity
Click Adjustment Value 1/4MOA
Windage Adjustment Range ≥50MOA
Elevation Adjustment Range ≥50MOA
Turret Style (Elevation) Tactical-profile, push-pull turret,Zero Stop
Turret Style (Windage) Tactical-profile, push-pull turret
Reticle Type (Etched / Fiber / Wire) Etched/Fiber (Can be customized)
Lens Coating Fully multi-coated lens
Construction Material One Piece Aluminum (6061)
Color & Finish Matte Black
Battery CR2032
Illumination 6-step red illu.(Optional)
Waterproof YES (submersible,30cm@52℃ 2mins or 1m @room temperature ,30 mins )
Fogproof YES (Nitrogen Purged)
Shockproof YES(1000G's)
Standard Accessories Filp-up covers/Lens Cloth
